Standard PCIe Transparent I/O Expansion Products
Dolphin offers a variety of standard PCIe products for transparent I/O expansion. These products range from PCIe Host and Target adapters to external cabled switchboxes. All standard products are designed to the PCI SIG specifications and can be connected to PCI SIG compliant products.
These products can be purchased in small quantities to evaluate PCIe or in large volume to support production applications.
PCIe x16 Gen 3 SFF-8644 / PCI 3.0 Host/Target Adapters
MXH832 Adapter
Microchip PCIe switch based
PCIe Gen3 x16 host and target adapter
Quad SFF-8644 cable port
PCI 3.0 cables and MiniSAS-HD cables
PCIe Gen 3.1 compliant
Support x4, x8, or x16 connections
Host clock isolation support
PXH832 Adapter
Broadcom PCIe switch based
PCIe Gen3 x16 host and target adapter
Quad SFF-8644 cable port
PCI 3.0 cables and MiniSAS-HD cables
Copper cables up to 9 meter
Fiber cables up to 100 meter
PCIe Gen 3.0 compliant
Support x4, x8, or x16 connections
Host clock isolation support
|
PCIe x8 Gen 3 iPass Host/Target Adapters
PXH812 Adapter
Broadcom PCIe switch based
PCIe Gen3 x8 Host and target adapter
iPass x8 Connector
Copper cables up to 5 meters
PCIe Gen 3.0 compliant
Host clock isolation support
MXH912 Adapter
Microchip PCIe switch based
PCIe Gen3 x8 Host and target adapter
iPass x8 Connector
Copper cables up to 5 meters
PCIe Gen 3.0 compliant
Host clock isolation support
|
PCIe 4.0 Host/Target Adapters
MXH932 Adapter
Microchip PCIe switch based
Host / Target adapter
PCIe Gen4 x16 host adapter
Quad SFF-8644 connectors
PCIe Gen 2 compliant
Support MXS924 switch
Host clock isolation support
MXH942 Adapter
Microchip PCIe switch based
Host / Target adapter
PCIe Gen4 x16 host adapter
Fiber cables up to 100 meter
PCIe Gen 4.0 compliant
Host clock isolation support
|
PCIe 4.0 Host Adapters
MXH914 Adapter
Microchip PCIe switch based
Host adapter
PCIe Gen4 x8 / x4 host adapter
Single SFF-8644 connector
PCIe Gen 4 compliant
Support MXS924 switch
Host clock isolation support
MXH919 Adapter
Microchip PCIe switch based
Host adapter
PCIe Gen4 x8 host adapter
Fiber cables up to 100 meter
PCIe Gen 4.0 compliant
Host clock isolation support
|
PCIe External Switch boxes
MXS824 Switch box
Microchip based External Switch box
24 x4 SFF-8644 ports
PCIe Gen 3.0 compliant
19 inch rack mount
Scalable to multiple switches
MXS924 Switch box
Microchip based External Switch box
24 x4 SFF-8644 ports
PCIe Gen 4.0 compliant
19 inch rack mount
Scalable to multiple switches
